TP-LINK 300Mbps Universal Wi-Fi Range Extender TL-WA850RE

TP-Link TL-WA850RE Specs

Interface 10/100 Mb/s RJ-45 Ethernet port
Button Range extender, reset, on/off
Antenna 2 x Internal
Power Consumption About 3 W
Plug Type US
Frequency 2.4 to 2.4835 GHz
Standard IEEE 802.11b/g/n
Signal Rate Dynamic:
11n: Up to 300 Mb/s
11g: Up to 54 Mb/s
11b: Up to 11 Mb/s
EIRP < 20 dBm
Reception Sensitivity 270M/130M/108M/54M: -68/-69 dBm @ 10% PER
6M: -88/-89 dBm @ 10% PER
11M: -85/-86 dBm @ 8% PER
1M: -90/-91 dBm @ 8% PER
Modes Range extender
Functions WMM (Wi-Fi multimedia)
Wireless MAC address filtering
Security Wireless statistic
Domain login function
System Requirements Microsoft Windows 8/7/Vista/XP/2000/ NT/98SE, Mac OS, NetWare, UNIX, or Linux
Environment Temperature
Operating: 32 to 104°F (0 to 40°C)
Storage: -40 to 158°F (-40 to 70°C)

Operating: 10 to 90% (non-condensing)
Storage: 5 to 90% (non-condensing)

Certifications CE, RoHS
Power 100-240 VAC, 50/60 Hz, 0.3 A
Dimensions (W x H x D) 4.3 x 3.0 x 2.6″ (109.2 x 76.2 x 66.4 mm)
Weight 3.17 oz (90.00 g)
Packaging Info
Package Weight 0.5 lb
Box Dimensions (LxWxH) 6.2 x 4 x 3.4″

In the Box

  • TP-Link TL-WA850RE N-300 Universal Wi-Fi Range Extender
  • RJ-45 Ethernet Cable
  • Limited 2-Year Warranty
Categories: ,


300 Mb/s Range Extender

The range extender is designed to conveniently extend the coverage and improve the signal strength of an existing wireless network to eliminate “dead zones.” This helps you to maintain an existing wireless network and vastly improve the network’s coverage. With 300 Mb/s wireless 802.11n speeds, it is suitable for smooth HD video, music streaming, and online gaming.

Flexible Deployment

The miniature size and wall-mounted design make it easy to deploy and move flexibly. Furthermore, the range extender profile function remembers previously paired wireless networks. There is no need to reset the device when changing the paired router.

Ethernet Bridge

Its single Ethernet port allows the extender to function as a wireless adapter to connect wired devices like Blu-ray players, gaming consoles, DVRs, and Internet TVs. At the same time, the device can share the wireless network as well

Smart Signal Indicator Light

Five signal lights represent the current signal strength that the range extender receives from the existing router, which can help you to find the right location to place it so that the device can achieve the best possible range and performance of the network


With no new wires or cables, within the range of your existing wireless network, you can easily extend wireless coverage at a push of the WPS button on your router followed by the range extender button on the device or vice versa. An additional push of the pair button can quickly establish an encrypted connection with client devices.

Domain Name-Based Login

It supports the domain name-based login ( for advanced management.


Advanced 64/128/152-bit WEP, WPA-PSK/WPA2-PSK encryptions protect your network from security threats.


The range extender works seamlessly with all 802.11 b/g/n wireless devices. It is also compatible with Windows 8 operating system.
